Download Datasheet

TMUX1308DYYR

Texas Instruments OEM P/N：TMUX1308DYYR
rohs compliant IC MUX 8:1 195OHM 16SOT23

9,770 pcs

N/A

SOT-23-16 Thin, SOT-23 Variant

$0.1247 (For reference only.)
QUICK RFQ

Specifications

Series Automotive, AEC-Q100 Switch Circuit SP8T
Multiplexer/Demultiplexer Circuit 8:1 Number of Circuits 1
On-State Resistance (Max) 195Ohm Channel-to-Channel Matching (ΔRon) 7Ohm
Voltage - Supply, Single (V+) 1.62V ~ 5.5V Voltage - Supply, Dual (V±) -
Switch Time (Ton, Toff) (Max) 32ns, 40ns -3db Bandwidth 500MHz
Charge Injection -6.5pC Channel Capacitance (CS(off), CD(off)) 14pF, 7pF
Current - Leakage (IS(off)) (Max) 1nA (Typ) Crosstalk -90dB @ 1MHz
Operating Temperature -40°C ~ 125°C (TA) Mounting Type Surface Mount
Package / Case SOT-23-16 Thin, SOT-23 Variant Supplier Device Package 16-SOT-23-THIN
