Download Datasheet

PTB48511BAH

Texas Instruments OEM P/N：PTB48511BAH
rohs compliant DC DC CONVERTER +/-12V 72W

6,740 pcs

N/A

8-DIP Module

Price: N/A
QUICK RFQ

Specifications

Series PTB4851x Type Isolated Module
Number of Outputs 2 Voltage - Input (Min) 36V
Voltage - Input (Max) 75V Voltage - Output 1 12V
Voltage - Output 2 -12V Voltage - Output 3 -
Voltage - Output 4 - Current - Output (Max) 3A, 3A
Power (Watts) 72 W Voltage - Isolation 1.5 kV
Applications ITE (Commercial) Features -
Operating Temperature -40°C ~ 85°C Efficiency 89%
Mounting Type Through Hole Package / Case 8-DIP Module
Size / Dimension 2.22" L x 1.45" W x 0.50" H (56.4mm x 36.8mm x 12.7mm) Supplier Device Package -
Control Features - Approval Agency -
Standard Number -
