Download Datasheet

DCP012405BP-U/700

Texas Instruments OEM P/N：DCP012405BP-U/700
rohs compliant DC DC CONVERTER 5V 1W

9,400 pcs

N/A

14-SMD Module, 7 Leads

Price: N/A
QUICK RFQ

Specifications

Series DCP01B (1W) Type Isolated Module
Number of Outputs 1 Voltage - Input (Min) 21.6V
Voltage - Input (Max) 26.4V Voltage - Output 1 5V
Voltage - Output 2 - Voltage - Output 3 -
Voltage - Output 4 - Current - Output (Max) 200mA
Power (Watts) 1 W Voltage - Isolation 1 kV
Applications ITE (Commercial) Features OTP, SCP
Operating Temperature -40°C ~ 100°C Efficiency 77%
Mounting Type Surface Mount Package / Case 14-SMD Module, 7 Leads
Size / Dimension 0.78" L x 0.33" W x 0.21" H (19.7mm x 8.3mm x 5.3mm) Supplier Device Package -
Control Features Enable, Active High Approval Agency -
Standard Number -
