Download Datasheet

VND5E012MYTR-E

STMicroelectronics OEM P/N：VND5E012MYTR-E
rohs compliant IC PWR SWTCH N-CHAN 1:1 PWRSSO36

22,410 pcs

N/A

36-BFSOP (0.295", 7.50mm Width) Exposed Pad

$2.8886 (For reference only.)
QUICK RFQ

Specifications

Series Automotive, AEC-Q100, VIPOWER™ Switch Type General Purpose
Number of Outputs 2 Ratio - Input:Output 1:1
Output Configuration High Side Output Type N-Channel
Interface On/Off Voltage - Load 4.5V ~ 28V
Voltage - Supply (Vcc/Vdd) Not Required Current - Output (Max) 52A
Rds On (Typ) 11mOhm Input Type Non-Inverting
Features Auto Restart Fault Protection Current Limiting (Fixed), Over Temperature, Over Voltage
Operating Temperature -40°C ~ 150°C (TJ) Mounting Type Surface Mount
Supplier Device Package PowerSSO-36 Package / Case 36-BFSOP (0.295", 7.50mm Width) Exposed Pad

Related Products

TDA7491MV
TDA7491MV

IC AMP D MONO 25W POWERSSO36

36-BFSOP (0.295", 7.50mm Width) Exposed Pad View
TDA7491P
TDA7491P

IC AMP D STEREO 10W POWERSSO36

36-BFSOP (0.295", 7.50mm Width) Exposed Pad View
TDA7492MV
TDA7492MV

IC AMP D MONO 50W POWERSSO36

36-BFSOP (0.295", 7.50mm Width) Exposed Pad View
L6701TR
